Sale!
10A Bridge Rectifier 1000V 4-PIN KBJ1010
Original price was: 70.00৳ .40.00৳ Current price is: 40.00৳ .
Specification of KBJ1010
- Model: KBJ1010
- Type: Bridge Rectifier
- Amp: 10A
- Volt: 1000V
- Package: KBJ
- Qty: 1Pcs
Features
- UL Listed Under Recognized Component Index,
- File Number E338195
- Glass passivated chip junctions
- High case dielectric strength
- Low Reverse Leakage Current
- High surge current capability
- Ideal for Printed Circuit Board Applications
Mechanical Data
- Case: KBJ
- Case Material: Molded Plastic. UL Flammability Classification Rating 94V-0
- Terminals: Pure tin plated, Lead free. Leads solder able per MIL-STD-750, Method 2026. .Polarity: Molded on Body
- Mounting: Through Hole for #6 Screw
- Mounting Torque: 5.0 in-lbs Maximum
- Weight: 4.3 grams
| Weight | 0.001 kg |
|---|
